Astra
A Minimalist System for Boundless Architecture.
Astra is a postless architectural guardrail system designed for projects where the edge should read as a single, continuous line. There are no vertical posts interrupting the view. The metal panel is the structure, and it connects directly to the building's fascia.
The result is a guardrail that provides safety and definition without visual weight. Light, views, and the building's own geometry stay in front, while the patterned metal surface and finish become the only visible expression of the system.
Astra is made for balconies, terraces, rooftop decks, stairs, walkways, and slab edges on contemporary residential, commercial, and mixed-use buildings. Every panel can be tailored in pattern, material, and finish to suit the architecture around it.
Designed to meet applicable building code requirements for guardrails, with compliance confirmed for each project, Astra combines the strength and durability of metal with a refined, minimal presence.
Astra’s postless design also offers greater flexibility for architectural detailing, allowing the guardrail to integrate seamlessly with different façade materials and building geometries. Custom laser-cut patterns create opportunities to balance privacy, openness, and visual identity, while durable metal construction supports long-term performance in demanding outdoor environments.
Materials and Finish Options
The 3D model could not be loaded.
Engineered without posts, Astra relies on the strength of the panel itself. Each metal panel is a self-supporting structural element, mounted to the side of the building edge and free of the vertical rhythm that conventional railings impose.
Available in laser cut patterns and solid designs, Astra lets the surface do the work: controlling privacy, openness, and light while staying visually restrained. Finishes in galvanized steel, stainless steel, powder coating, and Corten steel allow the system to blend with the facade or stand out as a deliberate architectural feature.
FEATURES
A Guardrail Without Posts
Conventional guardrails depend on a repeating series of posts. Astra removes them. The panel itself carries the load, so the railing reads as one uninterrupted surface along the edge of the building.
This keeps sightlines open, simplifies the visual language of balconies and terraces, and lets the pattern and finish of the metal take center stage. The result is a calmer, more architectural edge condition.
Side-Mounted by Design
Astra is a fascia-mounted system. Panels attach to the side of the slab or building edge rather than to the top surface. This keeps the walking surface clear and unobstructed, and it allows the guardrail to sit flush with the architecture.
Because Astra is designed exclusively for fascia mounting, it cannot be installed on top of the surface. Fascia conditions should be considered early in the design process so the mounting detail can be coordinated with the structure.
Visible or Concealed Mounting
Every Astra installation can be detailed in one of two ways. The mount can remain visible as a deliberate, honest connection, or it can be concealed behind a facade material such as insulation or cladding for a seamless finish.
Concealing the mount lets the panel appear to emerge directly from the facade, with no visible hardware at the connection. This flexibility gives architects and builders control over how much of the system is expressed.
Astra attaches to the fascia using one of two mounting options. Both can be left exposed or concealed behind a facade material.
- Fascia Mount A baseplate mount that fixes the panel to the face of the building edge. A straightforward, robust connection suited to a wide range of fascia conditions.
- Fascia Stanchion Mount The Artico mount, our own mounting system. It provides a refined connection and is designed to integrate cleanly with facade materials such as insulation.
Mounting Options
Configurations
Select a configuration.
Specifications
| Max. Panel Width | 72" |
|---|---|
| Max. Panel Height | 48" |
| Bend Depth | 1.5" |
| Openness Range | >30% |
| Max. Panel Width | 72" |
|---|---|
| Max. Panel Height | 48" |
| Bend Depth | 1.5" |
| Openness Range | >30% |
